Veer Flanges manufactures and distributes quality flanges in Kolkata India. Veer Flanges is known as a precision engineering company. Veer Flanges create Aluminium 5083 flanges which are known for high strength, resistance to corrosion and sea water and high durability in marine and other industrial applications. Veer Flanges uses state of the art manufacturing techniques and strictly allies with quality control measures for each production stage. Veer Flanges can be able to support and meet clients needs across Indian and International markets. Veer Flanges is well known because of its commitment to craftsmanship and customers satisfaction. They are a trusted name in the flange manufacturing sector.
Aluminum 5083 flanges are approximately 93 – 95% aluminum and 4 – 4.9% magnesium, along with 0.4 – 1% manganese, and other trace amounts of elements (possibly small amounts of chromium,) this is important to note since the combination of these elements creates excellent corrosion resistance in seawater and chemical resistance in extreme applications. In addition, 5083 aluminum flanges possess excellent mechanical properties, general tensile strengths of 270 – 350 MPa, yield strengths of 125 – 200 MPa and the aluminum has excellent weldability, and maintains its structure at sub-zero temperatures. Because of its properties, Aluminum 5083 flanges are typically used in marine, aerospace, and structural applications where corrosion resistance and strength is required.
Veer Flanges, a leading supplier in Kolkata, India, offers an extensive selection of Aluminium 5083 Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Standards : ASTM B247 / B/SB 247
Temper : H14
Thickness : 1 Mm To 100 mm
Diameter : Upto 2000 mm
Flange Diameter : 3″ DIA up to 38″ DIA 1500 lbs max
Flanges Form : Hot Rolled Flanges, Cold Rolled Flange, Proof Machined Flanges
Finish :Mill, Customer specific finish
Aluminum Flange Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
| Al | Cu | Mn | Cr | Si | Fe | Ti | Mg | Zn | Other Each | Others Total |
| Bal | 0.10 max | 0.40 / 1.0 | 0.05 / 0.25 | 0.40 max | 0.40 max | 0.15 max | 4.0 / 4.90 | 0.25 max | 0.05 max | 0.15 max |
| Tensile Strength | Hardness Brinell | Proof Stress | Elongation |
| 275 – 350 MPa | 75 HB | 125 Min MPa | 12 Min % |
Aluminium 5083 flanges are commonly used in marine and chemical applications and are ideal for industrial uses as well. They have excellent corrosion resistance in seawater and in some of the most aggressive chemical environments. For this reason, they also find their place in shipbuilding, in offshore platforms and structures, as well as in desalination plants and other chemical processing units. The unique physical properties of Al 5083, including its high strength-to-weight ratio also put it in aerospace structure or structural applications. They are suitable for cryogenic and low-temperature systems as well holding up under extreme and challenging conditions.
Yes, we offer custom sizes for Aluminium 5083 Flanges to meet specific project needs. Our team at Veer Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@veerflanges.co.in.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
