Veer Flanges based in Kolkata, India, is a leading manufacturer of industrial flanges, which are ANSI B16.47 flanges. Under the theme of precision engineering and high quality craftsmanship, the company mainly serves oil and gas industry, petrochemical industry and power generation industry. Veer Flanges has a rich product portfolio, having the solutions created to serve the international requirements, allowing them to perform and remain reliable in the long run. The company has the right expertise in human resources and with the modern manufacturing technology and will continue to give customized solutions to specific customer needs boosting its status as a leader in the field.
ANSI B16.47 flanges are normally produced through carbon steel, stainless steel or alloy steel, where some factors such as carbon, manganese, silicon and chromium are added to provide strength and corrosion- resistance. These flanges have the highest mechanical properties such as tensile strength and toughness properties and this makes the flanges suitable in high pressure uses. They have big sizes of between 26-60 inches and are leak-free and safe when used in a piping system. The exact size, quality of the surface finish, resistance to high temperatures render them quite applicable in harsh conditions within the oil, gas and chemical sectors.
Veer Flanges, a premier supplier in Kolkata, India, specializes in high-quality ANSI B16.47 Flanges, valued for their exceptional durability, corrosion resistance, precise engineering, and suitability across diverse industrial applications.
| pecifications | ANSI 16.47 Flanges |
|---|---|
| ANSI 16.47 Flange size range | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Main Types | Forged / Threaded / Screwed / Plate |
| Flange supporting material | Gasket, Ring Joint, Flange Bolts |
| Production technique | Forged, Heat treated and machined |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS 15 NB (1/2″) to 200 NB (8″) Equal and Reducing Configurations JIS Threaded Flange, Socketweld Flange, Slip-On Flange, Blind Flange, Weld Neck Flange |
| Specialized manufacturer of | DIN 2566 en 1092 1 Pn16 Flange DIN 2566 pn16 Rtj Flange ANSI 16.47 Sorf Flange ANSI 16.47 Table Flanges DIN 2566 pn10 ANSI 16.47 Large Diameter Flange ANSI 16.47 Threaded Flanges ANSI 16.47 Blind Flanges ANSI 16.47 Plate Flanges ANSI 16.47 Weld Neck Flanges ANSI 16.47 Loose Flanges ANSI 16.47 Orifice Flanges ANSI 16.47 Slip-On Flanges ANSI 16.47 Lap Joint Flanges ANSI 16.47 Socketweld Flanges ANSI 16.47 AS 4087 Water Flanges |
| Test | Hydrostatic testing machine, Direct-reading Spectrograph,UI trasonic flaw detector, X-ray detector, Magnetic particle detector |
| Equipment | Bending machine, Press machine, electric bevelling machine, Pushing Machine, Sand-blasting machine etc |
| Origin | West Europe /Indian / USA / Japan / Korean |
| Key markets and industries for ANSI B16.47 Flange | Nuclear power (mostly seamless). Heavy oil refineries. Bitumen upgraders. Petrochemicals and acids. |
| Export to | Indonesia, Ireland, Ukraine, Singapore,Saudi Arabia,Canada, Peru, Dubai, Brazil, Iran, Korea, USA, India, Egypt, Thailand, Spain, Oman etc |
| ANSI B16.47 Flanges Application | To Connect Pipe & Tubes in Power, Petroleum,Construction, Chemical, Gas, Shipbuilding,Metallurgy, etc |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| Nominal Size | Outside Diameter (OD) | Min. Thickness [Note1] – WNF (tf) | Min. Thickness [Note1] – Blind (tf) | Length Through Hub (Y) | Hub Dia. Base [Note2] (X) | Hub Dia. Top (A) | Raised Face Dia. (R) | Drilling – Bolt Circle Dia. | Drilling- No. of Bolt Holes | Drilling – Dia. of Bolt Hole | Dia. of Bolt | Min. Fillet Radius (r1) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 26 | 38.25 | 3.50 | 3.88 | 7.62 | 28.62 | 26.00 | 29.50 | 34.50 | 28 | 178 | 134 | 0.44 |
| 28 | 40.75 | 3.75 | 4.12 | 8.12 | 30.81 | 28.00 | 31.50 | 37.00 | 28 | 2 | 178 | 0.50 |
| 30 | 43.00 | 4.00 | 4.38 | 8.62 | 32.94 | 30.00 | 33.75 | 39.25 | 28 | 218 | 2 | 0.50 |
| 32 | 45.25 | 4.25 | 4.56 | 9.12 | 35.00 | 32.00 | 36.00 | 41.50 | 28 | 218 | 2 | 0.50 |
| 34 | 47.50 | 4.38 | 4.81 | 9.50 | 37.19 | 34.00 | 38.00 | 43.50 | 28 | 218 | 2 | 0.56 |
| 36 | 50.00 | 4.50 | 5.06 | 9.88 | 39.38 | 36.00 | 40.25 | 46.00 | 32 | 218 | 2 | 0.56 |
| 38 | 47.50 | 4.88 | 4.88 | 8.12 | 39.50 | 38.00 | 40.75 | 44.00 | 32 | 178 | 134 | 0.56 |
| 40 | 50.00 | 5.12 | 5.12 | 8.50 | 41.50 | 40.00 | 43.00 | 46.25 | 32 | 2 | 178 | 0.56 |
| 42 | 52.00 | 5.25 | 5.25 | 8.81 | 43.62 | 42.00 | 45.00 | 48.25 | 32 | 2 | 178 | 0.56 |
| 44 | 54.50 | 5.50 | 5.50 | 9.18 | 45.62 | 44.00 | 47.25 | 50.50 | 32 | 218 | 2 | 0.56 |
| 46 | 56.75 | 5.75 | 5.75 | 9.62 | 47.75 | 46.00 | 49.50 | 52.75 | 36 | 218 | 2 | 0.56 |
| 48 | 59.50 | 6.00 | 6.00 | 10.12 | 49.88 | 48.00 | 51.50 | 55.25 | 28 | 238 | 214 | 0.56 |
| 50 | 61.75 | 6.19 | 6.25 | 10.56 | 52.00 | 50.00 | 53.62 | 57.50 | 32 | 238 | 214 | 0.56 |
| 52 | 63.75 | 6.38 | 6.44 | 10.88 | 54.00 | 52.00 | 55.62 | 59.50 | 32 | 238 | 214 | 0.56 |
| 54 | 67.00 | 6.69 | 6.75 | 11.38 | 56.12 | 54.00 | 57.88 | 62.25 | 28 | 258 | 212 | 0.56 |
| 56 | 69.00 | 6.88 | 6.94 | 11.75 | 58.25 | 56.00 | 60.12 | 64.25 | 32 | 258 | 212 | 0.56 |
| 58 | 71.00 | 7.00 | 7.12 | 12.06 | 60.25 | 58.00 | 62.12 | 66.25 | 32 | 258 | 212 | 0.56 |
| 60 | 74.25 | 7.31 | 7.44 | 12.56 | 62.38 | 60.00 | 64.38 | 69.00 | 32 | 278 | 234 | 0.56 |
The ANSI B16.47 flanges mostly feature in industries which deal with large-diameter piping systems, namely, oil and gas, petrochemicals, power generation and water treatment. These flanges are designed to create safe and leak free connections on pipes with 26 to 60 inches in diameter, hence perfect in high-pressure and high-temperature purposes. They are important in such a system which needs strength, durability, and corrosion resistance of the system. Typical applications are pipeline connections, storage tanks, reactors, pressure vessels and heat exchangers (onside and offsite).
Yes, we offer custom sizes for ANSI B16.47 Flanges to meet specific project needs. Our team at Veer Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@veerflanges.co.in.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
