Veer Flanges, a leading manufacturer and supplier based in Kolkata, India, specializes in high-quality DIN 2527 PN6 Blind Flanges. Designed for low-pressure systems, these flanges provide secure, leak-proof connections in a variety of industries, including oil and gas, water treatment, and petrochemical. Known for their durability and precision, Hudson’s flanges ensure optimal sealing and system performance. Trust Veer Flanges for reliable, top-tier products that meet the most demanding industrial requirements.
DIN 2527 PN6 Blind Flanges are typically made from carbon steel, stainless steel, or alloy steel, offering excellent corrosion resistance and durability. These flanges provide moderate tensile strength and the ability to withstand low-pressure environments. The flat face design ensures a secure, leak-proof seal when used to close pipe ends. Advantages include ease of installation, minimal maintenance, and the ability to withstand temperature and pressure fluctuations. They are ideal for use in pipelines, valves, and process systems where secure sealing is essential in industries such as water treatment, oil and gas, and petrochemical.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Screws | Weight (7,85 Kg/dm3) | ||||
|---|---|---|---|---|---|---|---|
| D | b | k | Number | Thread | d2 | Shape B | |
| Kg | |||||||
| 15 | 80 | 12 | 55 | 4 | M 10 | 11 | 0.44 |
| 20 | 90 | 14 | 65 | 0.66 | |||
| 25 | 100 | 14 | 75 | 0.83 | |||
| 32 | 120 | 14 | 90 | M 12 | 14 | 1.18 | |
| 40 | 130 | 14 | 100 | 1.39 | |||
| 50 | 140 | 14 | 110 | 1.63 | |||
| 65 | 160 | 14 | 130 | 2.15 | |||
| 80 | 190 | 16 | 150 | M 16 | 18 | 3.44 | |
| 100 | 210 | 16 | 170 | 4.22 | |||
| 125 | 240 | 18 | 200 | 8 | 6.11 | ||
| 150 | 265 | 18 | 225 | 7.51 | |||
| 200 | 320 | 20 | 280 | 12.31 | |||
| 250 | 375 | 22 | 335 | 12 | 18.54 | ||
| 300 | 440 | 22 | 395 | M 20 | 22 | 25.46 | |
| 350 | 490 | 22 | 445 | 31.77 | |||
| 400 | 540 | 22 | 495 | 16 | 38.49 | ||
| 500 | 645 | 24 | 600 | 20 | 60.10 | ||
Veer Flanges, a leading supplier in Kolkata, India, offers an extensive selection of DIN 2527 PN6 Blind Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2527 PN6 Blind Flanges are primarily used to seal the ends of pipes, valves, or pressure vessels in low-pressure systems. They are widely used in industries such as oil and gas, water treatment, chemical processing, and petrochemicals. These flanges help close off unused or maintenance openings in pipelines and equipment, preventing leakage and ensuring system integrity. Their durable construction and secure sealing capability make them ideal for applications where pressure and temperature fluctuations are minimal, providing a reliable and cost-effective solution for system maintenance and isolation.
Yes, we offer custom sizes for DIN 2527 PN6 Blind Flanges to meet specific project needs. Our team at Veer Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@veerflanges.co.in.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| DIN 2527 PN6 BLRF Flanges Supplier in Kolkata | Alloy Steel DIN 2527 PN6 Blind Flanges Manufacturer in India |
| DIN 2527 PN6 Blind Flange Dimensions | Raised Face DIN 2527 PN6 Blind Flange Manufacturer |
| 18 inch DIN 2527 PN6 Carbon Steel Blind Flange | DIN 2527 PN6 Blind Flange Dimensions in mm |
| Stainless Steel DIN 2527 PN6 Blind Flange | ASTM B564 Raised Faced DIN 2527 PN6 Blind Flanges |
| DIN 2527 PN6 Blind FF Flange Supplier | Suppliers of DIN 2527 PN6 Blind Flange |
| Alloy Steel DIN 2527 PN6 Blind Flanges | Copper Nickel DIN 2527 PN6 Blind Flanges at Best Price |
| 8 Inch DIN 2527 PN6 Blind Pipe Flanges | DIN 2527 PN6 Blind Flanges Stockist |
| DIN 2527 PN6 BLRF Flange Stockist in India | Raised Faced DIN 2527 PN6 Slip-On flanges Dealer in Kolkata |
| Nickel Alloy DIN 2527 PN6 Blind Flange | Mild Steel DIN 2527 PN6 Blind Flange |
| DIN 2527 PN6 BLRF Flange Exporter | DIN 2527 PN6 Blind Flange Pressure Ratings |
| Raised Face DIN 2527 PN6 Blind Plate Flanges | Titanium DIN 2527 PN6 Blind Flanges |
| 30 inch DIN 2527 PN6 Blind Flange Dealer | Raised Face DIN 2527 PN6 Blind Flanges Manufacturer |
| DIN 2527 PN6 Large Diameter Blind Flange | 30 Inch DIN 2527 PN6 Blind Pipe Flange Dimensions |
| 4 inch Stainless Steel DIN 2527 PN6 Blind Flange | DIN 2527 PN6 Blind RF Flanges Stockholder |
| DIN 2527 PN6 Blind Flanges Supplier in India | MS DIN 2527 PN6 Blind Flange |
| Carbon Steel Raised Face DIN 2527 PN6 Blind Flange Stockist | Duplex Steel DIN 2527 PN6 BLRF Flanges Supplier in India |
| DIN 2527 PN6 Blind Pipe Flanges Wholesaler | DIN 2527 PN6 BLRF Flanges Supplier |
| DIN 2527 PN6 Blind Flange Manufacturer | Flat Face DIN 2527 PN6 Blind Flange Manufacturer |
| DIN 2527 PN6 BLRF Flanges Distributor in India | Flat Face DIN 2527 PN6 Blind Flanges Exporter |
| German Standard DIN 2527 PN6 Blind Flanges | DIN 2527 PN6 Blind Flange Supplier in India |
| ASME SA105N Raised Faced DIN 2527 PN6 Blind Flanges | 18 inch Carbon Steel DIN 2527 PN6 Blind Flange |
| DIN 2527 PN6 Blind Pipe Flanges Supplier in Kolkata | Duplex Steel DIN 2527 PN6 Blind Flanges |
| Carbon Steel DIN 2527 PN6 Blind Flange | DIN 2527 PN6 Blind RF Flange Supplier |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
