Veer Flanges, a name to reckon with in the metal industry, is one of the pioneering manufacturers and suppliers of titanium plate flanges in Kolkata, India. The company, driven by innovation and quality, offers high-precision flanges that conform to international standards for strength, durability, and resistance to corrosion. Supported by state-of-the-art manufacturing facilities and rigorous quality checks, Veer Flanges supplies products to a wide range of industries such as oil & gas, chemical processing, power generation, and shipping. Their titanium plate flanges are produced in multiple sizes and specs for consistent performance in high-temperature, high-pressure, and corrosive conditions on critical applications. Titanium Plate Flanges consist mainly of high-purity titanium (usually greater than 99.5%), together with trace quantities of elements such as iron, oxygen, carbon, nitrogen, and hydrogen.
The flanges have superior corrosion resistance, especially against oxidizing and chloride-containing environments. They have a high strength-to-weight ratio, a good fatigue life, and minimal thermal expansion. Mechanical properties have a tensile strength of around 344–550 MPa, yield strength of about 275 MPa, elongation of 20–30%, and hardness of 70–160 HB based on the grade used (e.g., Grade 2 or Grade 5), so they are best suited for strenuous industrial activities. Titanium Plate Flanges are extensively utilized in industries where corrosion resistance, light weight, and strength are a must.
| Specifications | ASTM B381 / ASME SB381 |
| Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Grades | Titanium Gr. 1, Titanium Gr. 2, Titanium Gr. 4, Titanium Gr. 5, Titanium Gr. 7 |
| Dimensions | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Size | 1 / 2” to 18″ |
| Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Flange Type | Plate Flanges |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
Veer Flanges, a premier supplier in Kolkata, India, specializes in high-quality Titanium Plate Flanges. They are valued for their exceptional durability, corrosion resistance, precise engineering, and suitability across diverse industrial applications.
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 | 3.7035 | R50400 |
| Titanium Gr. 5 | 3.7165 | N56400 |
Yes, we offer custom sizes for Titanium Plate Flanges to meet specific project needs. Our team at Veer Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@veerflanges.co.in.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Typical uses of such flanges are heat exchangers, pressure vessels, ship hardware, chemical process equipment, aeronautical components, and medical devices. In the oil & gas and offshore industries, these flanges are utilized because they can withstand harsh saline and acidic conditions. Their biocompatibility also allows them to be used for biomedical implants. Additionally, their non-magnetic attributes are useful in delicate electronic and defense applications, highlighting their adaptability in various markets.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
